Fakra Male PCB Mount Angled
RF Coaxial Connector – High-Performance Solution for Compact Electronic Systems This precision-engineered Fakra male angled RF coaxial connector offers a reliable, space-saving connection method for printed circuit boards in demanding environments. Designed with automotive-grade durability and optimized for high-frequency signal integrity, it ensures consistent performance across a wide operating range—from DC to 6 GHz—making it ideal for modern communication systems where compact design meets robust functionality. Key Features: - Angled PCB mount configuration allows efficient cable routing in tight spaces, reducing strain on solder joints and improving mechanical stability - Fakra male interface provides secure, low-loss connectivity commonly used in vehicle telematics, GPS modules, and wireless sensors - Nickel-plated brass body with plastic insulation delivers excellent corrosion resistance and long-term reliability under vibration, temperature extremes (-40°C to +105°C), and humidity exposure - 50 Ohm impedance matched construction minimizes signal reflection and ensures optimal transmission efficiency for RF applications - Two-pin layout supports standard Fakra pinout configurations for easy integration into existing designs without rework - Solderable through-hole terminals simplify assembly and reduce risk of misalignment during PCB mounting The connector’s angled geometry not only enhances physical accessibility but also promotes better thermal dissipation and mechanical resilience compared to straight-mount alternatives. Its durable build makes it well-suited for use in harsh industrial and automotive settings where environmental stressors such as shock, moisture, and thermal cycling are common. With minimal insertion loss and superior shielding effectiveness, this component maintains signal clarity even at elevated frequencies, ensuring stable operation in radar systems, antenna interfaces, and mobile broadband equipment. Ideal Applications: - Automotive infotainment and ADAS systems requiring reliable antenna connections - Wireless communication modules in IoT devices and embedded platforms - Industrial RF transceivers and test instrumentation - PCB-based antenna solutions for satellite communications and 5G infrastructure - Signal distribution networks in telecom base stations and repeaters Users consistently report improved installation speed due to the intuitive angled footprint and clear terminal labeling. The connector’s ability to maintain consistent performance over time—especially in vehicles subjected to frequent acceleration, deceleration, and temperature shifts—has made it a trusted choice among engineers designing next-generation electronic systems. Many customers appreciate the balance between form factor flexibility and electrical performance, particularly when working within constrained board layouts or multi-layered PCB architectures. Common Questions: Why is this angled
Fakra Connector preferred over straight versions? Its 90-degree orientation enables easier trace routing and reduces the need for additional connectors or bends in cables, which can degrade signal quality or create stress points in the assembly. How do you ensure product consistency across batches? Each unit undergoes pre-production sampling and final inspection before shipment, guaranteeing dimensional accuracy, electrical continuity, and mechanical strength in every lot. What other RF components does your company supply? We offer a comprehensive line including SMA, SMB, DIN, circular, Mini Fakra, and HSD connectors—all designed for similar applications requiring reliable, high-frequency interconnects. What support services are available for international clients? We provide flexible logistics options including FOB, CIF, EXW, and express shipping; accept payments in USD or CNY via T/T, PayPal, Western Union, or Escrow; and communicate in English or Chinese to accommodate global teams.
Product Categories : Automotive Connector > Fakra Connector
