Male Female Fakra HSD LVDS RF Cable Adapter

High-Speed Data LVDS Connector – 100 Ohm Differential Transmission Solution for Reliable Digital Signal Transfer

This advanced 4-pin male-female HSD LVDS RF Connector is engineered for high-performance digital communication in demanding environments. Designed with a precise 100-ohm impedance, it supports differential signaling standards like LVDS (Low Voltage Differential Signaling), ensuring minimal signal degradation over long distances and across various industrial and automotive applications. Whether you're integrating video systems, camera modules, or real-time data interfaces, this connector delivers consistent, high-speed transmission with exceptional reliability.

Key Features:

• Optimized for high-speed data transmission using a 100 ohm differential architecture—ideal for LVDS-based protocols such as MIPI DSI, DisplayPort, and HDMI signals.
• Constructed from premium-grade plastic and metal components to resist environmental stressors including moisture, dust, vibration, and temperature fluctuations.
• Supports multiple digital standards within a single interface—reducing the need for separate connectors across different devices.
• Easy-to-install design suitable for both professional engineers and technical hobbyists working on embedded systems or custom hardware setups.
• Customizable color and code options available upon request—enhancing traceability and system organization in complex installations.

Detailed Description:

The connector features a compact 4-pin configuration that ensures efficient routing of clock, data, and ground lines while minimizing crosstalk and electromagnetic interference (EMI). Its robust mechanical structure includes precision-molded housing and gold-plated contacts for stable electrical performance even under continuous operation. With an industry-standard impedance matching of 100 ohms, it maintains signal integrity at speeds up to several gigabits per second, making it ideal for modern applications requiring low-latency, high-bandwidth connections. The durable materials used—such as PBT plastic and brass alloy terminals—are selected not only for longevity but also for compliance with international safety and durability standards (e.g., RoHS and IP67-rated sealing capabilities).

Common Use Cases:

This versatile HSD RF connector finds widespread use in automotive infotainment systems, industrial control panels, surveillance cameras, medical imaging equipment, and robotics where fast, reliable, and noise-resistant signal transfer is critical. It’s especially effective in scenarios involving high-frequency analog-to-digital conversion, such as in ADAS (Advanced Driver Assistance Systems) or machine vision setups. Additionally, its compatibility with various cable types—including shielded twisted pair and coaxial variants—makes it adaptable to diverse signal routing needs.

User Feedback Highlights:

Customers frequently praise the connector’s plug-and-play functionality and resistance to wear in harsh conditions. Many report improved signal stability compared to generic alternatives, particularly when deploying it in outdoor or mobile environments. One engineer noted, “It’s rare to find a small connector that performs this reliably at 1 Gbps+ speeds—it’s now our go-to for all new projects.” Another user appreciated the ability to customize colors for labeling purposes: “We label each channel by color—this makes troubleshooting much faster during production runs.”

Frequently Asked Questions:

Q: Can I use this connector for non-LVDS signals? A: While primarily optimized for LVDS, it can support other low-voltage differential formats provided the impedance remains close to 100 ohms and the pinout is correctly matched. Always verify compatibility with your specific signal protocol.

Q: Is it suitable for high-frequency applications beyond 500 Mbps? A: Yes, thanks to its controlled impedance and low insertion loss, it performs well up to 2 Gbps depending on cable quality and layout. For higher rates, consider using shorter cables and proper grounding techniques.

Q: Do you offer bulk customization for codes and colors? A: Absolutely—we provide OEM/ODM services for unique marking schemes, enabling tailored identification for large-scale deployments or proprietary systems.

Product Categories : Automotive Connector > Hsd Connector
