Right Angle MCX Male Plug RF Coaxial Adapter

Right Angle MCX Male Plug RF Coaxial Adapter – Compact, High-Performance Connection for Space-Constrained RF Applications

This right-angle MCX male plug adapter is engineered for precision and reliability in demanding RF environments. Designed with a 90-degree bend, it offers an optimal solution for routing coaxial cables in tight enclosures without compromising signal integrity or mechanical stability. Ideal for engineers, technicians, and hobbyists working with compact electronics, this connector ensures seamless integration between MCX female receptacles and compatible RF components—whether in field deployments, lab setups, or embedded systems.

Key Features:

• Space-Saving Right-Angle Design: Eliminates sharp bends in cabling by allowing horizontal cable exit from vertical connectors—a critical advantage in PCB layouts, handheld devices, and industrial enclosures where space is at a premium.
• MCX Male Interface: Compatible with standard MCX female interfaces found on antennas, modules, and test equipment; provides secure, low-resistance mating for consistent performance across frequencies up to 6 GHz.
• Durable Nickel-Plated Brass Construction: Resists corrosion, withstands repeated mating cycles, and maintains electrical continuity even under vibration or thermal stress—ideal for outdoor and mobile applications.
• Minimal Insertion Loss & High Return Loss: Engineered for low VSWR (Voltage Standing Wave Ratio), ensuring efficient power transfer and reduced signal degradation in high-frequency wireless systems such as LTE, Wi-Fi, and GPS modules.
• Wide Operating Temperature Range: Functions reliably from -20°C to +70°C, making it suitable for both indoor and outdoor use in diverse climates—from cold storage facilities to hot industrial settings.

Technical Details:

Impedance: 50 Ohms | Frequency Range: Up to 6 GHz | Material: Nickel-plated brass housing with insulated contacts | Connector Type: Right Angle MCX Male | Mating Cycles: >500 | Environmental Resistance: IP67-rated sealing potential when mated properly. This adapter supports high-speed data transmission while maintaining compliance with EMI/EMC standards common in telecommunications and IoT device manufacturing.

Common Use Cases:

Engineers deploying compact RF front-ends in drones, satellite communication terminals, and portable radar units rely on this adapter to simplify internal wiring. It’s also widely used in GPS tracking devices, automotive telematics systems, and wireless sensor networks where minimizing footprint and maximizing signal fidelity are essential. For professionals conducting RF testing or calibration, the stable impedance match reduces measurement uncertainty—making it a trusted component in lab-grade instrumentation setups.

User Feedback Highlights:

“I’ve used several brands of MCX adapters—this one stands out for its build quality and clean fit. No loose connections after weeks of field testing.” — Electrical Engineer, Europe “Perfect for my custom Raspberry Pi-based LoRa gateway. The right angle allows me to route the cable neatly inside the enclosure instead of bending it sharply.” — Hobbyist, North America “Consistent signal strength over long-term operation. Even in humid conditions, there's no sign of oxidation or poor contact.” — Technician, Australia

Frequently Asked Questions:

Can I use this with SMA or BNC connectors? No—it is specifically designed for MCX-to-MCX interconnection only. Using it with other connector types may result in improper fit or signal loss. Is it suitable for outdoor installations? Yes, thanks to its nickel plating and robust design, it performs well in harsh environments when properly sealed. How does it compare to straight MCX connectors? The right-angle version minimizes strain on cables and prevents micro-fractures that can occur from repeated bending—especially beneficial in high-vibration applications like vehicles or aerospace gear. What tools are needed for installation? Standard torque screwdrivers and crimping tools for MCX cables are sufficient. No special tools required.

Whether you're designing next-gen wireless hardware or optimizing existing RF infrastructure, this right-angle MCX male plug adapter delivers dependable connectivity in constrained spaces. Its combination of durability, frequency stability, and ergonomic form factor makes it a top choice among global professionals seeking reliable RF solutions.

Product Categories : RF Coaxial Connector > Mcx Connector
