Dacar 535 4-Pin A-Code Waterproof Fakra HSD Male to Female Automotive LVDS
Wire Harness – High-Speed, Reliable Data Transmission for Modern Vehicle Electronics This premium automotive-grade LVDS wire harness is engineered for seamless and robust high-speed signal transmission in demanding vehicle environments. Featuring a Fakra HSD A-code male plug mated with an HSD female connector, it leverages Dacar 535 low-loss coaxial cable to deliver exceptional performance for rearview camera systems, ADAS modules, infotainment displays, and other LVDS-based automotive electronics. Designed with precision engineering and rigorous testing, this harness ensures consistent signal integrity even under extreme conditions such as vibration, moisture exposure, or electromagnetic interference. Key Features: - Connector A: Fakra HSD 4-pin male plug (A-Code, waterproof/IP67-rated) - Connector B: HSD 4-pin female receptacle - Mechanical coding via A-Code keying (blue color-coded for easy identification) - Dacar 535 shielded coaxial cable—automotive-grade material ensuring minimal signal attenuation - IP67 waterproof rating on the male side when fully mated - 100 ohm impedance for optimal differential signaling in LVDS applications - Frequency range up to 6 GHz for ultra-fast data transfer - Full 360° shielding to protect against EMI/RFI noise - Customizable length based on OEM project specifications - Over 100 mating cycles for long-term durability - Compliant with RoHS standards, LVDS protocols, and global automotive quality benchmarks The Dacar 535 cable used in this assembly offers superior dielectric properties, making it ideal for transmitting high-definition video streams without distortion. Unlike standard cables that degrade over time due to heat, flexing, or environmental stress, this harness maintains stable electrical characteristics across thousands of hours of operation. The A-code mechanical keying prevents incorrect mating—a critical safety feature in automotive installations where misconnections can lead to system failure or hazardous outcomes. This design simplifies wiring processes during vehicle assembly or repair while reducing installation errors. Ideal Applications: This LVDS wire harness supports a wide array of modern automotive technologies including rearview cameras, 360-degree surround-view systems, lane departure warning units, blind-spot detection sensors, and advanced telematics interfaces. It also serves as a reliable solution for connecting head units, dashcams, and onboard diagnostic tools that require clean, high-bandwidth data links. Whether integrated into electric vehicles, autonomous driving platforms, or luxury passenger cars, this harness meets the growing demand for faster, more secure, and durable connectivity solutions in today’s smart mobility ecosystem. User Benefits: Engineers and installers appreciate the combination of rugged construction, accurate impedance matching, and weather-resistant capabilities. Its ability to maintain signal clarity at frequencies exceeding 6 GHz makes it suitable for 4K video transmission from multiple cameras simultaneously—an essential requirement for next-generation driver assistance systems. With built-in protection against dust, water ingress, and electromagnetic noise, this harness performs reliably in harsh outdoor climates, from arctic winters to desert summers. Frequently Asked Questions: What makes this harness suitable for automotive use? It combines Dacar 535 low-loss cable with IP67-rated connectors and full electromagnetic shielding—critical for maintaining signal integrity in dynamic vehicle environments. Can I request custom lengths or configurations? Yes, we offer tailored solutions including right-angle connectors, multi-branch harnesses, and specialized routing options to match your specific vehicle architecture needs. Is this compatible with existing LVDS systems? Absolutely—it adheres to industry-standard LVDS protocols and works seamlessly with most OEM and aftermarket video/data interfaces. How does the A-code system improve safety? The blue-colored, mechanically keyed connector ensures only correct mating pairs are used, preventing accidental misconnections that could compromise system functionality. Are there alternative connectors available? We supply various types including Mini Fakra, HSL, and RF connectors to meet diverse application requirements beyond standard Fakra HSD setups.
Product Categories : Automotive Connector > Wire Harness
